MCP-Server-V3

MCP Server AI Chrome Extension

A lightweight AI-powered Chrome Extension connected to a Flask-based MCP Server, enabling users to perform complex BODMAS (Bracket, Order, Division, Multiplication, Addition, Subtraction) operations directly from the browser.

---

✨ Features

• 📚 Solve complex mathematical expressions with full BODMAS hierarchy.
• ⚡ Instant real-time computation via a backend AI MCP server.
• 🧠 Server processes user input with decision-making and memory modules.
• 🌐 Simple and clean Chrome Extension interface.
• 🔌 Easy communication between Chrome Extension and Flask API server.

---

🏗️ Project Structure

MCP-Server-V3/
│
├── flask-api/
│   ├── action.py           # Handles mathematical operations
│   ├── decision.py         # Decides actions based on parsed user input
│   ├── memory.py           # Maintains session memory and history
│   ├── mcp_server.py       # Main Flask server running the API
│   ├── mcp_client.py       # Client utilities (if needed)
│   ├── models.py           # Defines data models for input/output
│   ├── perception.py       # Parses and understands user queries
│   └── requirements.txt    # Python dependencies
│
├── chrome-extension/
│   ├── manifest.json       # Chrome extension manifest
│   ├── popup.html          # Extension popup frontend
│   ├── popup.js            # JS logic to interact with backend server
│
├── requirements.txt        # Top-level requirements
│
└── README.md               # 📄 (You are here!)

---

🚀 How It Works

1. User Interaction:

   • User opens the Chrome Extension popup.
   • Enters a math expression (e.g., 5 * (3 + 2) - 4 / 2).

2. Chrome Extension (Frontend):

   • Captures the user input.
   • Sends a POST request to the Flask MCP Server API.

3. Flask API (Backend Server):

   • Parses the input via perception.py.
   • Uses decision.py and action.py to compute the correct BODMAS result.
   • Returns the final output back to the Chrome Extension.

4. Result Display:

   • Extension receives the response.
   • Displays the computed answer to the user in the popup.

---

🛠️ Installation Guide

1. Set Up the MCP Server

# Clone the repo
git clone https://github.com/shettysaish20/MCP-Server-V3.git
cd MCP-Server-V3/flask-api

# Install Python dependencies
pip install -r requirements.txt

# Run the server
python mcp_client.py

By default, server runs at: http://localhost:5000/

---

2. Set Up the Chrome Extension

• Open chrome://extensions/ in Chrome.
• Enable Developer Mode.
• Click Load unpacked and select the chrome-extension/ folder.
• Extension will appear in the browser toolbar.

---

3. Usage

• Click on the MCP extension icon.
• Type a BODMAS-based math query.
• View instant computed results!

---

📦 Dependencies

• Backend (Python):

  • Flask
  • Flask-Cors

  (All backend libraries are listed in requirements.txt.)

• Frontend (Extension):

  • Pure JavaScript + HTML/CSS (no external libraries).

---

🚀 Running

---

📄 License

MIT License.
Feel free to modify, extend, and enhance as you wish!

---

👨‍💻 Author

Built with ❤️ by Saish Shetty

---
