MCP for IOT

Model Context Protocol (MCP) Server for IoT Devices (Arduino)

IOT MCP Logo

Overview

MCP for IOT is a Go implementation of the Model Context Protocol (MCP) server that allows AI models like Claude to directly interact with IoT devices, specifically Arduino boards. This server acts as a bridge between Claude and your Arduino hardware, enabling AI-controlled hardware automation.

Features

🔌 List available serial ports
📡 Read data from Arduino's serial port
🚦 Control digital pins (LEDs, relays, etc.)
🔊 Control buzzers with on/off and duration settings
🤖 Seamless integration with Claude AI

Usage

https://github.com/user-attachments/assets/46d7d731-f5d0-4acd-b53e-c00be8b83215

Prerequisites

Go (version 1.24 or later)
Arduino hardware with USB connection
Claude Desktop App or compatible MCP client

Installation

Build from Source

git clone https://github.com/sukeesh/mcp-iot-go.git
cd mcp-iot-go
go install

The binary will be installed to your GOBIN directory, which should be in your PATH.

Arduino Setup

Connect your Arduino to your computer
Upload the provided Arduino firmware:
```
arduino/firmware.ino
```

This firmware accepts commands via serial communication:

M,pin,mode - Sets pin mode (e.g., M,6,OUTPUT)
D,pin,value - Controls digital pins (e.g., D,6,HIGH or D,6,LOW)
BZ,pin,state - Controls buzzers (e.g., BZ,8,ON or BZ,8,OFF)

Configuration with MCP Client

Configure Claude Desktop:

Open Claude Desktop → Settings → Developer → Edit Config
Add the following to your claude_desktop_config.json:

{
  "mcpServers": {
    "iot": {
      "command": "<path-to-mcp-iot-go-binary>",
      "env": {}
    }
  }
}

Restart Claude Desktop

Available Tools

Tool	Description
`port_list`	Lists all available serial ports
`read_serial_line`	Reads a single line of data from a specified serial port
`write_digital`	Writes a digital value (HIGH/LOW) to a pin on a specified port
`buzzer_control`	Controls a buzzer connected to an Arduino pin with optional duration

Usage Examples

After setup, you can interact with your Arduino hardware directly through Claude:

"List all available serial ports"
"Read data from the Arduino on port /dev/cu.usbmodem12401"
"Turn on the red LED on pin 6"
"Activate the buzzer on pin 8 for 2 seconds"

Development

Project Structure

main.go - MCP server setup and tool definitions
internal/tools.go - Tool implementation for Arduino communication
arduino/firmware.ino - Arduino firmware for processing commands

Dependencies

mcp-go - Go library for MCP implementation
go.bug.st/serial - Serial port communication library

Contributing

Contributions are welcome! Please feel free to submit a Pull Request.
